Material & specs

Natural gypsum, classified A1

Cast in natural gypsum, a mineral material, reinforced with glass fibre.

Gypsum

Beta natural gypsum as standard; alpha on request where project requirements call for it

Glass fibre

1 % as standard; 5 % on request where project requirements call for it

Reaction to fire

classified A1 (EN 13501-1) - non-combustible

CE marking

EN 15283-2

DoP

KANDES-3DGP-DoP-001 Rev. 1

Key figures

Panel thickness

8 to 32 mm

Density

1130 kg/m³ (EN 15283-2)

Format

500 x 500 mm, most designs

Finish

unfinished chalk-white

Use

dry interior walls

• Sizes and weightsPer design, on its product page.
• Your designWrite the model you are interested in to check its specifications.

Opens kandes.eu

Fire resistance belongs to the wall

• EI30A fire-resistance class of the complete wall assembly (EN 13501-2); no cladding carries it alone.
• Kandes panelsClassified A1 (EN 13501-1) - non-combustible: they add no fuel and no fire load.
• Typical build-upsIn typical build-ups the panels do not degrade the wall's fire performance.
• Tested configurationAn EI rating is certified for the wall system's tested configuration.
• Confirm per projectWith the wall-system manufacturer or the fire-safety planner: that the rated wall keeps its classification with the cladding and its fixings attached.

Projects in Switzerland: under the Swiss fire protection regulations, A1 materials (EN 13501-1) are assigned to fire-behaviour group RF1 (VKF fire protection guideline 13-15, assignment table 2.4.1).

Documents

• Technical Data SheetMaterial, format, use, storage.
• Declaration of Performance, Rev. 1CE marking under EN 15283-2.
• Compliance SummaryThe A1 test results.

All three by e-mail, from info@kandes.ch.
